Details
Why should you be forced to choose between aerodynamics and weight, between ride quality and speed? It’s simple, you shouldn’t. Enter the new Tarmac—climb on the lightest bike the UCI allows, then descend on the fastest. We’ve utilized our most advanced technologies, from our FreeFoil Shape Library to an all-new Rider-First Engineered™ frame, to deliver a race bike that is truly without compromise. The days of making sacrifices between “aero” and “lightweight” bikes are over—the all-new Tarmac is the fastest race bike, ever. One bike to rule them all.
To complement the world’s fastest frame, only the best components will do—which is why you’ll find the likes of Shimano’s Dura-Ace group with power meter and Roval’s new CLX Rapide wheels with their exceptional stability and aerodynamic prowess. The S-Works Tarmac is a top-level race machine, right out of the box.
'Aero is everything'—we’ve been preaching it for years and it’s still the driving force for the new Tarmac. In our quest for tube shapes that deliver the fastest frame that the UCI rules allow, we took a page out of the Venge development book and utilized our FreeFoil Shape Library. Armed with a library of optimized shapes, we turned to the Win Tunnel to plug these shapes into a modular test bike, for more testing and validation. The result? A new Tarmac that’s the fastest we’ve tested—45 seconds faster over 40km than the Tarmac SL6. No compromises, just pure speed.
While aerodynamics were paramount to the Tarmac’s development, and to the development of all of our race bikes, weight was the co-pilot on this optimal race bike journey. Previously “aero bikes” always compromised in the weight department—the more drag you reduced, the more weight you gained. With the new Tarmac, our design philosophy was to keep it at, or below, the UCI weight limit out of the box, with no sacrifices to aerodynamics. And with the help of the FreeFoil Shape Library, tools like isotopic FEA analysis, and some engineering wizardry by the best engineers in the industry, we delivered a frame that weighs a mere 800 grams, without giving up a gram of aero, stiffness or ride quality.
Continuing our quest to develop the perfect race bike, we used our Rider-First Engineered™ philosophy to ensure that the new Tarmac is the most balanced, best handling Tarmac yet—no matter the size. With an army of the world’s best test riders from our three World Tour Teams — Boels-Dolmans, Deceuninck-Quick-Step, and Bora-hansgrohe — we made changes to the Tarmac based on their thousands of kilometers on the road. We balanced the ride quality between the front and rear end, so even the longest days in the saddle continue to be comfortable—all without giving up anything to the Tarmac’s legendary handling and race-winning snappiness
Building on the learnings from the Venge, the new Tarmac utilizes simple integration to create a clean, fast cockpit that’s easy to live with. We’ve improved the routing for any configuration — mechanical shifting, traditional stems, round bars, etc. — all while keeping its aerodynamic attributes. These same traits also make the new Tarmac easy to work on and easy to travel with. It’s a win-win.
44 49 52 54 56 58 61 Crank Length
165
165
170
172.5
172.5
175
175
Handlebar Width
380
380
400
420
420
440
440
Stem Length
70
80
90
100
100
110
110
Saddle Width
155
155
155
143
143
143
143
Seatpost Length
300
300
300
380
380
380
380
BB Drop
74
74
74
72
72
72
72
Wheelbase
970
973
975
978
991
1006
1013
Top Tube Length, Horizontal
496
509
531
541
563
577
595
BB Height
266
266
266
268
268
268
268
Chainstay Length
410
410
410
410
410
410
410
Seat Tube Length
435
447
458
475
496
517
547
Stack
491
504
517
534
555
581
602
Reach
369
378
383
387
398
405
411
Head Tube Length
93
102
113
131
151
178
198
Fork Rake/Offset
47
47
47
44
44
44
44
Front Center
572
574
577
579
592
606
613
Seat Tube Angle
75.5
75.5
74
74
73.5
73.5
73
Fork Length, Full
366
366
366
366
366
366
366
Bike Standover Height
723
735
746
768
786
808
834
Head Tube Angle
70.5
71.75
72.5
73
73.5
73.5
74
Trail
71
63
58
58
55
55
52
Specs
Frame | S-Works Tarmac SL7 FACT 12r Carbon, Rider First Engineered™, Win Tunnel Engineered, Clean Routing, Threaded BB, 12x142mm thru-axle, flat-mount disc |
---|---|
Fork | S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc |
Headset | Integrated |
Rear Shock | None |
Rims/Wheels | Rear Wheel Roval Rapide CLX, Tubeless, 21mm internal width carbon rim, 60mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes Front Wheel Roval Rapide CLX, Tubeless, 21mm internal width carbon rim, 51mm depth, Win Tunnel Engineered, Roval AFD hub, 18h, DT Swiss Aerolite spokes |
Tires | S-works Turbo Rapidair 2BR, 700x26mm |
Crankset | Crankset Shimano Dura-Ace R9200, HollowTech II, 12-speed with 4iiii Precision Pro dual-sided powermeter |
Chainwheel | Chainrings 50/34T |
Bottom Bracket | Bottom Bracket Shimano Dura-Ace, BB-R9100 |
Chain | Shimano XTR M9100, 12-speed w/ quick link |
Front Derailleur | Front Derailleur Shimano Dura-Ace R9250, braze-on |
Rear Derailleur | Rear Derailleur Shimano Dura-Ace R9250, 12-speed |
Rear Cogs | Cassette Shimano Dura-Ace, 12-speed, 11-30t |
Shifters | Shift Levers Shimano Dura-Ace R9270, hydraulic disc |
Handlebars | Handlebars Roval Rapide Handlebar, carbon |
Tape/Grips | Tape Supacaz Super Sticky Kush |
Stem | Stem Tarmac integrated stem, 6-degree |
Brake Levers | Shimano Dura-Ace R9270, hydraulic disc |
Brakes | Dura Ace Hydro |
Pedals | None |
Saddle | Body Geometry S-Works Power, carbon fiber rails, carbon fiber base |
Seat Post | 2021 S-Works Tarmac Carbon seat post, FACT Carbon, 20mm offset |
Seat Binder | Tarmac integrated wedge |
Accessories & Extras | Integrated Computer Mount and Dual Legged Power Meter |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
SATIN RED ONYX GRANITE OVER BLACK / 52cm | 888818863792 | 90623-0152 | |
SATIN RED ONYX GRANITE OVER BLACK / 54cm | |||
SATIN RED ONYX GRANITE OVER BLACK / 56cm | |||
SATIN RED ONYX GRANITE OVER BLACK / 58cm | |||
SATIN RED ONYX GRANITE OVER BLACK / 61cm | |||
GLOSS BLACK PEARL GRANITE OVER CARBON / 49cm | |||
GLOSS BLACK PEARL GRANITE OVER CARBON / 52cm | |||
GLOSS BLACK PEARL GRANITE OVER CARBON / 54cm | |||
GLOSS BLACK PEARL GRANITE OVER CARBON / 56cm | 888818863815 | 90623-0056 | 210000045547 |
GLOSS BLACK PEARL GRANITE OVER CARBON / 58cm | |||
GLOSS BLACK PEARL GRANITE OVER CARBON / 61cm |
